Driver Convenience

Front and rear smart entry

Functional module switch for driver seat

Handsfree power back door

Parking assist monitor with on-screen guard

Push button start

Tailgate electric lift and close

Tailgate height memory function

Entertainment

10 speakers premium audio system

2 front USB C and 2 rear USB C charging points

AM/FM and DAB radio

AUX socket with VTR compatibility

Steering wheel mounted audio controls

Exterior Body Features

Aero stabilising arch mouldings

Body adhesive, laser screw welding and laser brazed roof structure

Body colour roof drip mouldings

Body coloured door handles

Body coloured roof spoiler

Chrome door belt moulding

Chrome moulding side windows frame

F mesh signature grille

F SPORT badge front wings

F SPORT exterior styling

F Sport front bumper jet black bumper and grille garnish

F Sport rear bumper

F SPORT stainless steel scuff plates with LEXUS

Front and rear performance rod

Lexus chrome plated rear badge

Paint protection film

Rear side wing doors

Resin rear scuff plates

Shark fin roof aerial

Silver roof rails

Single hidden exhaust pipe

Interior Features

12V accessory port centre console and luggage compartment

2 cup holders in the front and rear centre console

2 x folding shopping bag hooks in boot

3 spoke perforated leather trimmed steering wheel with paddle shift

4 x tie down hooks in the boot

Active sound control

Black roof lining

Card holder installed in driver and passengers sun visors

Centre armrest with storage

Driver and passenger door pocket

Driver side machined aluminium footrest

Glovebox

Heated steering wheel

Integral knee pads for front centre console

LED glove box light

Luggage cover manually folding

Machined aluminium sports pedals

Perforated leather gearshift

Rear center armrest

Smooth leather F sport upholstery

Storage tray under audio panel

Tahara door panel finish

Tahara meter hood

Tilt/telescopic adjustable electric steering wheel

Touch Screen Cloth

Under deck storage

Under desk side storage

Safety

2 x Isofix child rear seat restraints

3x3 point rear seatbelts

Acoustic vehicle alerting system

Driver and front passenger 2 stage airbag

Driver and front passenger knee airbag

Driver/front passenger side airbags

Electric child locks

Front adjustable seatbelt anchor points

Front and rear curtain shield airbags

Front outer seatbelt+pre-tensioners,force limiter+tension reduction: 3-point with active safety link to PCS

Passenger airbag cut-off device

Rear outer seatbelt+pre-tensioners,force limiter+tension reduction: 3-point with active safety link to PCS,Centre belt w/o pre tensioner+force limiter

Tyre pressure warning

Security

2 x remote key fobs

Anti theft system : Alarm instruction sensor,glass breakage sensor and engine immobiliser

Digital key

Intrusion sensor

Locking wheel nuts

Remote central door locking

Smart digital key

Smart start system

Speed sensitive auto door locking

Tilt sensors

Two motion door lock with double lock

Ultra wide band security

VIN Window etching

Wireless door lock

Electric Vehicle Data

Battery Capacity in kWh	1.6
Battery Type	Lithium-ion

Emissions - ICE

Standard Euro Emissions	EURO 6
WLTP - CO2 (g/km) - Comb	127
WLTP - CO2 (g/km) - Comb - TEH	129
WLTP - CO2 (g/km) - Comb - TEL	127
WLTP - CO2 (g/km) - Extra High	160
WLTP - CO2 (g/km) - Extra High - TEH	161
WLTP - CO2 (g/km) - Extra High - TEL	160
WLTP - CO2 (g/km) - High	113
WLTP - CO2 (g/km) - High - TEH	114
WLTP - CO2 (g/km) - High - TEL	113
WLTP - CO2 (g/km) - Low	111
WLTP - CO2 (g/km) - Low - TEH	112
WLTP - CO2 (g/km) - Low - TEL	111
WLTP - CO2 (g/km) - Medium	105
WLTP - CO2 (g/km) - Medium - TEH	106
WLTP - CO2 (g/km) - Medium - TEL	105

Engine and Drive Train

Camshaft	DOHC
Catalytic Convertor	True
CC	1987
Compression Ratio	14.0:1
Cylinder Layout	IN-LINE
Cylinders	4
Cylinders - Bore (mm)	80.5
Cylinders - Stroke (mm)	97.6
Engine Layout	FRONT TRANSVERSE
Fuel Delivery	MULTI POINT FUEL INJECTION
Gears	1 SPEED
Number of Valves	16
Transmission	AUTO

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies	False
WLTP - FC (l/100km) - Comb	5.6
WLTP - FC (l/100km) - Comb - TEH	5.7
WLTP - FC (l/100km) - Comb - TEL	5.6
WLTP - FC (l/100km) - Extra High	7
WLTP - FC (l/100km) - High	5
WLTP - FC (l/100km) - Low	4.9
WLTP - FC (l/100km) - Medium	4.6
WLTP - MPG - Comb	50.4
WLTP - MPG - Comb - TEH	49.5
WLTP - MPG - Comb - TEL	50.4
WLTP - MPG - Extra High	40.3
WLTP - MPG - High	56.4
WLTP - MPG - Low	57.6
WLTP - MPG - Medium	61.4

General

Alternative Fuel Qualifying	True
Badge Engine CC	2.0
Badge Power	199
Coin Description	h E4
Coin Series	F-Sport
Generation Mark	1
Insurance Group 1 - 50 Effective January 07	27E
Man Corrosion Perforation Guarantee - Years	12
Manufacturers Paintwork Guarantee - Years	3
Safety Concerns	False
Service Interval Frequency - Months	12
Service Interval Mileage	10000
Special Edition	False
Special Order	False
Standard manufacturers warranty - Mileage	60000
Standard manufacturers warranty - Years	3
Vehicle Homologation Class	M1

Performance

0 to 62 mph (secs)	7.9
Engine Power - BHP	199
Engine Power - KW	146
Engine Power - PS	True
Engine Power - RPM	6000
Engine Torque - LBS.FT	140
Engine Torque - MKG	19.4
Engine Torque - NM	190
Engine Torque - RPM	4400
Top Speed	110

Test Cycles

Emissions Test Cycle	WLTP
RDE Certification Level	RDE 2

Tyres

Alloys	True
Space Saver	False
Tyre Size Front	225/50 R18
Tyre Size Rear	225/50 R18
Tyre Size Spare	RUN FLAT TYRES
Wheel Type	18" ALLOY

Vehicle Dimensions

Height	1540
Length	4495
Wheelbase	2640
Width	1840
Width (including mirrors)	2080

Weight and Capacities

Fuel Tank Capacity (Litres)	43
Gross Vehicle Weight	2110
Max. Loading Weight	555
Max. Towing Weight - Braked	750
Max. Towing Weight - Unbraked	750
Minimum Kerbweight	1555
No. of Seats	5
