Driver Convenience

E Save

eCall emergency system

Stop/start system

Tailgate

Wireless phone charger

Entertainment

10.1" media nav live with connected navigation, DAB, smartphone replication, bluetooth, connected services, 6 speakers, USB-C plug (front and rear)

USB connection for data transfer and charging

Exterior Body Features

Black with white trim radiator grille

Body coloured door handles

Copper air vent inserts

Front and rear body coloured bumpers

Front door sill protection strip

Grey front skid plate

Modular roof bars

Rear roof spoiler

Rear side wing doors

Side protection

Underbody protection skid plates

Wheel arch protection and snorkel in starkle

Interior Features

Front 12v plug

Height and depth adjustable steering wheel

High central armrest with console storage

Rear 12v plug in boot

Steel grey interior door handles

Synthetic leather steering wheel

Synthetic leather TEP upholstery

Safety

3x3 point rear seatbelts

6 airbags - front and side driver and passengers including curtain airbags

Alcohol imoboliser predisposal

Child locks on rear doors

Door open visual and audible warning

Driver and passenger seatbelt not fastened warning

Front seatbelt pretensioners

Height adjustable front seatbelts

Side impact protection

Tyre pressure monitor

Security

Automatic central locking

Engine immobiliser

Keyless entry

Remote central locking

Electric Vehicle Data

Battery Capacity in kWh	1.2
Battery Type	Lithium-ion

Emissions - ICE

Standard Euro Emissions	EURO 6
WLTP - CO2 (g/km) - Comb	114

Engine and Drive Train

Camshaft	DOHC
Catalytic Convertor	True
CC	1598
Cylinder Layout	IN-LINE
Cylinders	4
Cylinders - Bore (mm)	78
Cylinders - Stroke (mm)	83.6
Engine Code	H4M632
Engine Layout	FRONT TRANSVERSE
Fuel Delivery	MULTI POINT FUEL INJECTION
Gears	4 SPEED
Number of Valves	16
Transmission	AUTO

Fuel Consumption - ICE

EC Directive 1999/100/EC Applies	False
WLTP - FC (l/100km) - Comb	5.1
WLTP - FC (l/100km) - Extra High	6.2
WLTP - FC (l/100km) - High	4.4
WLTP - FC (l/100km) - Low	4.6
WLTP - FC (l/100km) - Medium	4.3
WLTP - MPG - Comb	55.4
WLTP - MPG - Extra High	45.6
WLTP - MPG - High	64.2
WLTP - MPG - Low	61.4
WLTP - MPG - Medium	65.7

General

Alternative Fuel Qualifying	True
Badge Engine CC	1.6
Badge Power	140
Coin Description	Hybrid 140
Coin Series	Extreme
Generation Mark	3
Insurance Group 1 - 50 Effective January 07	24A
NCAP Adult Occupant Protection %	70
NCAP Child Occupant Protection %	84
NCAP Overall Rating - Effective February 09	3
NCAP Pedestrian Protection %	60
NCAP Safety Assist %	57
Safety Concerns	False
Special Edition	False
Special Order	False
Vehicle Homologation Class	M1

Performance

0 to 62 mph (secs)	10.1
Engine Power - BHP	140
Engine Power - KW	104
Engine Power - PS	True
Engine Power - RPM	5600
Engine Torque - LBS.FT	109
Engine Torque - MKG	15.1
Engine Torque - NM	148
Engine Torque - RPM	3600
Top Speed	106

Test Cycles

Emissions Test Cycle	WLTP
RDE Certification Level	RDE 2

Tyres

Alloys	True
Space Saver	False
Tyre Size Front	215/60 R18
Tyre Size Rear	215/60 R18
Tyre Size Spare	TYRE REPAIR KIT
Wheel Style	TAGASAN
Wheel Type	18" ALLOY

Vehicle Dimensions

Height	1616
Height (including roof rails)	1656
Length	4343
Wheelbase	2657
Width	1813
Width (including mirrors)	2069

Weight and Capacities

Fuel Tank Capacity (Litres)	50
Gross Vehicle Weight	1870
Luggage Capacity (Seats Down)	1545
Luggage Capacity (Seats Up)	472
Max. Loading Weight	490
Max. Towing Weight - Braked	750
Max. Towing Weight - Unbraked	725
Minimum Kerbweight	1380
No. of Seats	5
Turning Circle - Kerb to Kerb	10.86
